DESCRIPTION
The KH13 is a special designed for KTV fixed installation, two way full range speaker, in the human music listening sense has a good performance. Unit configuration: 1x13" high efficiency mid-bass unit, 1x1" exit throat 44mm HF driver with 100°×70° rotatable horn. The cabinet is made of multilayer composite plywood with water-based environmental protection paint.
FEATURES
●Rotatable horn
●Multi-hanging points to meet different demands of installation
●Back vented design with rich bass sound
●Applications: KTV entertainment
SPECIFICATIONS
MODEL | KH13 |
FREQUENCY RESPONSE(-3dB) | 50Hz-16KHz |
FREQUENCY RESPONSE(-10dB) | 45Hz-18KHz |
DRIVERS | 1×13"(350mm)/3"voice coil LF |
1×1"(25mm) / 1.7"voice coil HF | |
RATED POWER | 400W RMS,1600W peak |
SENSITIVITY | 97dB 1watt/1 metre |
MAXIMUM SPL | 123dB continuous,129 dB peak |
IMPEDANCE | 8 ohms nominal |
DISPERSION(-6dB) | 100° x 70° |
CROSSOVER FREQUENCIES | 2KHz passive |
INPUT CONNECTORS | 2×Speakon NL4 |
PACKAGE SIZE | 406mm×490mm×645mm |
NET WEIGHT | 27 kg/pc |
GROSS WEIGHT | 30 kg/pc |
