MR12/MR12A/MR12N/MR12NA
12" 2-way loudspeaker system
DESCRIPTION
MR112 is compact, small height size, coaxial, 12" two-way full range monitor series speaker with different configurations, has balanced and real sound quality. Configuration:1x12" high efficency mid-bass unit and 1x1" exit throat 44mm voice coil HF driver with special designed horn. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint. The model with N is a neodymium magnetic unit, and the model with A is active.
FEATURES
●High quality components, high strength plywood housing
●Small height, take small space
●Can be placed on stage , can be hung
●Applications: Stage monitor
●Small height, take small space
●Can be placed on stage , can be hung
●Applications: Stage monitor
SPECIFICATIONS
| MODEL | MR112/ MR112N | MR112A/ MR112NA |
| FREQUENCY RESPONSE(-3dB) | 75Hz-18kHz | 75Hz-18KHz |
| FREQUENCY RESPONSE(-10dB) | 70Hz-20kHz | 70Hz-20kHz |
| DRIVERS | 1×12"(300mm)/3"voice coil LF | 1×12"(300mm)/3"voice coil LF |
| 1×1"(25mm)/1.7"voice coil HF | 1×1"(25mm) / 1.7"voice coil HF | |
| RATED POWER | 300W RMS,1200W peak | 600W/8Ω |
| SENSITIVITY | 97dB 1watt/1 metre | -- |
| MAXIMUM SPL | 122dB continuous,128dB peak | 122dB continuous,128dB peak |
| IMPEDANCE | 8 ohms nominal | -- |
| DISPERSION(-6dB) | 70°×40° | 70° × 40° |
| CROSSOVER FREQUENCIES | 2.3kHz passive | -- |
| INPUT CONNECTORS | 2×Speakon NL4 | INPUT TYPE：Balanced Differential line |
| PACKAGE SIZE | 560mm×425mm×545mm | 560mm×425mm×545mm |
| NET WEIGHT | 24 kg/pc; 20kg/pc | 26 kg/pc; 22kg/pc |
| GROSS WEIGHT | 27 kg/pc; 23kg/pc | 29 kg/pc; 25kg/pc |
